Other 1993 Yamaha WR500 Teardown/Overhaul
- Thread starter SRAD97750
- Start date
HEY! is that my hammer??
Dan, looks like that air filter has seen one or two rides
Dan, looks like that air filter has seen one or two rides
-BIG DAN
Mounted up my new wrench holders that I got from Christmas.
Anyways, I'm getting to the end of the FREE part of this rebuild. Here I am breaking down my wheels.
This photo is of a stripped screw I need to extract. First I need to nip the head off this countersunk screw.
GOT IT! Then I used an extractor to pull the remaining shank.
Rear rotor and some random swingarm bushings and associated hardware.
The casualties of the rebuild. Notice the triple clamp nuts.... they welded together and ate threads....
Rear rotor and Sprocket removal
Random photo
Tires and tubes. All need replacement.
Wheel breakdown. Had a really hard time with these rear spokes. They are straight... so they spin in their recesses. Took a few pairs of visegrips and a ton of patience... not to mention the WD40 I used....
So I added a rotor screw and a rear rim to the list of things that are required. Along with the triple clamp nuts, which worked fine the last time I replaced the steering stem bearings. Must have over tightened the nut. OH well.
Next I'm putting together the shopping list including prices.
Engine teardown coming shortly also. I know some of you have wet dreams including pistons and rods... sickos...
-BIG DAN
Anyways, I'm getting to the end of the FREE part of this rebuild. Here I am breaking down my wheels.
This photo is of a stripped screw I need to extract. First I need to nip the head off this countersunk screw.
GOT IT! Then I used an extractor to pull the remaining shank.
Rear rotor and some random swingarm bushings and associated hardware.
The casualties of the rebuild. Notice the triple clamp nuts.... they welded together and ate threads....
Rear rotor and Sprocket removal
Random photo
Tires and tubes. All need replacement.
Wheel breakdown. Had a really hard time with these rear spokes. They are straight... so they spin in their recesses. Took a few pairs of visegrips and a ton of patience... not to mention the WD40 I used....
So I added a rotor screw and a rear rim to the list of things that are required. Along with the triple clamp nuts, which worked fine the last time I replaced the steering stem bearings. Must have over tightened the nut. OH well.
Next I'm putting together the shopping list including prices.
Engine teardown coming shortly also. I know some of you have wet dreams including pistons and rods... sickos...
-BIG DAN
Holy crap your hubs are HUGE!
thats what she saidHoly crap your hubs are HUGE!
Only vinyl decals for me! Thinking traditional race numbers, or like a sweet lazer beam!
These are some decals I have done for past bikes
Painting plastics sucks.... -BIG DAN
These are some decals I have done for past bikes
I did remove alot of spray paint... took about 45 minutes, with a palm sander, to sand 2 fairings and half the tank down to fresh plastic.Frikkin spray paint bombers
Painting plastics sucks.... -BIG DAN
